Electrical parameters

Input Voltage

AC220V±20%

AC220V±20%

AC380V±20%

AC380V±20%

Input   Frequency

45-60Hz

Rated Power

7kW

14kW

21kW

42kW

Output   Voltage

AC220V±20%

AC220V±20%

AC380V±20%

AC380V±20%

Current   Limiting Protection Value

1.1

Output   Current

32A

32A+32A

3*32A

3*32A+3*32A

Appearance structure

Installation   Method

Floor-standing

Wiring Method

Lower inlet and lower outlet

Product Size

300*150*1400mm

Product   Weight

/

Human-Computer   Interaction

4.3-inch high-brightness LCD screen / LED indicator   light strip

Cable Length

Standard 3.0M (optional)

Functional Design

Charge Mode

Automatic charging / Select fixed electricity amount   /

Select fixed amount   of money / Select fixed time

Charge Method

APP payment / scanning code for charging / swiping card   for charging

Networking   Method

Ethernet/4G

OperationMode

Offline billing / No offline billing / Online   billing

Execution   Standards

GB/ T20234、GB/ T18487、GB/ T27930、NB/ T33008、NB/ T33002

Protection   Function

Overvoltage protection, undervoltage protection,   overload protection, short circuit protection, grounding protection,   overtemperature protection, communication abnormality protection, emergency   stop protection, and leakage protection

Environmental Indicators

Operation   Temperature

-20°C~+50°C

Working   Humidity

5%~95％（No frost）

Working   Altitude

<2000m

Protection   Grade

IP54

Cooling   Method

Air Cooling

Noise Control

<40dB

MTBF

30,000h
