Equipped with self-developed power module, it can output high charging power (80kW) with high efficiency (>96%the output voltage of it can realize a wide range of 200-1000Vdc, which can meet most of EVs in the market andsupport high voltage charging.
Using a new design, this charger can also support AC charging so that one parkingcan support three EVs charging simultaneously.
Support highpower charging
The Sinexcel 80kW DC charger support atmaximum 80kW power charging and systemcan output at maximum 200A current.
Support DC and ACcharging simultaneously
There is an AC charging connector in this DCcharger, which realizes the AC charging (22kW)and charges for three EVs at the same time.
High efficiency
Equipping with high performance powermodule(SER 100020K2C],the DC charger canoutput the power greater than 96%.
Smallfloor space
The DC charger takes small space, which isfriendly for the customer.
| Category | Item | Parameter |
| Input Characteristic | Name | MKS-9035 |
| Input type | 3P+N+PE | |
| Input voltage | 400Vac±10% | |
| Input frequency | 50~60Hz | |
| THDi | <5% | |
| Power factor | 0.99 | |
| Output Characteristic | Output power | 80kW DC+22kW AC |
| Maximum output current | 200A@CCS | |
| Output voltage | 200-1000V | |
| Connector type | CCS, CHAdeMO, Type 2 | |
| Peak efficiency | 96% | |
| Environment & Appearance | Temperature | -25~65 |
| Humidity | 5%~95% | |
| Dimensions | W850*D450*H2030mm | |
| Structure | 304 Stainless steel | |
| Others | Payment | RFID/Credit/QR code |
| Standby power | <0.1% max power | |
| Network method | Ethernet/4G | |
| IP/IK degree | IP55/IK10 | |
| Certification | CE, TUV, UKCA, TR25, RCM | |
| Protection | Undervoltage protection, Overvoltageprotection, DC Overcurrent protection,Over-temperature protection, SurgeProtection Device, Emergency StopProtection |
