Electrical specifications

Rated Power

Main Cabinet

Charging Terminal

Liquid Cooling    Charging Terminal

600kW

720kW

Single-Gun

Dual-Gun

Single-Gun

Output Voltage

DC 200-(750)1000V

DC 200-1000V

Input Current

0-1200A

0-1400A

5-250A

0-600A

Output Current

5-1500A

5-1800A

5-2000A

5-2400A

Input Voltage

AC 380V ±15%

DC 200-1000V

Input Frequency

45-60Hz

Wiring Method

Lower inlet and lower outlet

Product Dimensions

1300*1000*2200mm

400*240*1500mm

1630*500*370mm

Cable Length

5m

Measurement Accuracy

Class 1.0

Efficiency

≥95%

Current Limit Protection Value

≥110%

Voltage Regulation Accuracy

≤±0.5%

Current Regulation Accuracy

≤±1%

Efficiency

≥95%

Power Factor

≥0.99 (at 50% load   or above)

Functional Design

Charging Mode

Auto Full Charge/Select Target   Capacity/Select Target Amount/Select Target Time

Charging Method

VIN Code/Plug & Charge/Card   Swiping/QR Code Charging/Password Charging

Networking Method

Ethernet/4G

Operation Mode

Offline Billing/Offline   Non-billing/Online Billing

Compliance Standards

GB/T20234, GB/T18487, GB/T27930,   NB/T33008, NB/T33002

Protection Functions

Gun Temperature Detection,   Over-voltage Protection, Under-voltage Protection, Overload Protection, Short   Circuit Protection, Grounding Protection, Over-temperature Protection,   Low-temperature Protection, Insulation Monitoring Protection, Reverse   Polarity Protection, Lightning Protection, Emergency Stop Protection, Leakage   Protection

Environmental Specifications

Operating Temperature

-20°C ~ +50°C

Operating Humidity

5%~95% (non-condensing)

Operating Altitude

≤2000m

Protection Class

IP54

Noise Control

≤60dB

MTBF

17520 hours
