Intelligent BMS: The built-in Intelligent Management System (BMS) protects the battery from overcharge,
overdischarge, overload, overheating and short circuit. And with custom power on/off, low power sleep,
shake-to- restart(only gently shake the vehicle or battery), one-key restart battery and other functions.
Safety: lithium iron phosphate battery has good chemical stability, low self-discharge, no memory effect,
and higher safety performance when it is charged.
5V 2.4A Dc输出、支持快充;
Environmental protection: lithium iron phosphate battery is non-toxic (SGS certified), does not contain lead,
mercury and other toxic substances, no pollution, in line with European RoHS regulations.
Model | MKS12-025F | MKS12-035F | MKS12-050F | MKS12-060F | MKS12-080F | MKS12-120F | MKS12-180F |
Nominal Voltage | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V |
Nominal Capacity | 2.5AH | 3.5AH | 5AH | 6AH | 8AH | 12AH | 18AH |
Watt-hour | 30W | 42W | 60W | 72W | 96W | 144W | 216W |
Cranking Ampere | 150A | 210A | 300A | 360A | 480A | 720A | 1080A |
Cold Cranking Ampere | 75A | 105A | 150A | 180A | 240A | 360A | 540A |
Max. Constant Discharge Current | 50A 20C | 70A 20C | 100A 20C | 120A 20C | 160A 20C | 240A 20C | 360A 20C |
Max. Charge Current | 12.5A 5C | 17.5A 5C | 25A 5C | 30A 5C | 40A 5C | 60A 5C | 90A 5C |
Charging Cut-off Voltage | 14.6V | 14.6V | 14.6V | 14.6V | 14.6V | 14.6V | 14.6V |
Discharge Cut-off Voltage | 8.0V | 8.0V | 8.0V | 8.0V | 8.0V | 8.0V | 8.0V |
Range Of Operating Temperature-Charge | 0~55℃ | 0~55℃ | 0~55℃ | 0~55℃ | 0~55℃ | 0~55℃ | 0~55℃ |
Range Of Operating Temperature-Discharge | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ |
Weight | 0.7KG | 0.8KG | 1.1KG | 1.3KG | 1.6KG | 2.6KG | 2.8KG |
Terminal Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
Standard Dimension (mm) | 113*70*85mm | 113*70*85mm | 150*87*93mm | 150*87*93mm | 150*87*130mm | 175*87*155mm | 166*126*175mm |
