Marxon

Model		MKS-HC51200Y5	MKS-HC51300Y5	MKS-HC51400Y5
Electrical Characteristics	Rate voltage(VDC)	51.2	51.2	51.2
	Module rate capacity(AH)	200	150	200
	Built in module quantity	2	4	4
	Energy storage(KWH)	10.2	15.3	20.4
	Cycle life	DOD(≥1800 cycles to 85% DOD).
	Months self discharge	≤2%
	Efficiency of charge	100% at 0.2C
	Efficiency of discharge	96~99% at 1C
	Built in BMS(Yes/No)	YES
Standard Charge	Charge voltage(Vdc)	58.4±0.2V
	Charge mode	0.2C to58.4V, then 58.4V,charge current to 0.02C(CC/CV)
	Charge current(A)	40	60	80
	Max. charge current(A)	60	90	120
	Charge cut-off voltage(Vdc)	54.8±0.2V
Standard	Contiunous current(A)	60	90	120
Discharge	Discharge cut-off voltage(VDC)	40
Environmental	Charge temperature	0℃ to 45℃
	Discharge temperature	-20℃ to 60℃
	Storage temperature	0℃ to 40℃
Mechanical	IP class	IP60
	Material system	LiFePO4
	Case material	Metal
	Dimensions: HWD(mm)	1050600600
	Weight(kg)	280	350	590
	Terminal	M8
	Protocol(Optional)	SMBus/RS485/RS232
	SOC(Optional)	LED/LCD
	The quality assurance period	60 Months
