LC-8138
Battery Tester
Product features
Features
Display batteries status fast and correctly.
Detect battery charging system and starting system, CCA,current, battery life and internal resistance.
Product parameters
Parameters
| Specifications | C-8138 | ||
| Input voltage | DC8~15V | ||
| Battery type | 12V lead-acid battery | ||
| Voltage accuracy | ±0.1V | ||
| Battery internal resistance accuracy | ±10% | ||
| Standard | CCA | 100-2000 | ±10% |
| DIN | 100-1400 | ±10% | |
| JIS | 26A17-58815 | ±10% | |
| EN | 100-2000 | ±10% | |
| IEC | 100-1400 | ±10% | |
| GB | 30-220AH | ±10% | |
| SAE | 100-2000 | ±10% | |
| CA | 100-2000 | ±10% | |
| Test method | Conductivity test method | ||
| Test item | Internal resistance, CCA, life time, starting system and charging system | ||
| Operation temperature | -20℃-50℃ | ||
| Operation humidity | 20%-80% | ||
| Language | Chinese, English, Japanese and Korean | ||
| Dimension | 185*91*26mm | ||
| Weight | 0.5kg | ||
