Home > Products > > MSI-400P Plastic Version

MSI-400P

Plastic Version

Clean and Stable Power ensures the smooth and consistent operation of electrical appliances and electronics.

Intelligent Operation reduces power consumption and saves battery reserve capacity.

Versatile Safety features short circuit, fault leakage, over-load, over-temperature, under-voltage and over-voltage shut down.

Product features

Features

Input Voltage 12V /24V/48V DC optional

Output Voltage 115V /230V AC optional

Portable power for AC products, AC outlets for connecting multiple loads

High surge capacity for products that require more power to start

High efficiency converts virtually all of the battery's power to AC

Mounting brackets for convenient installation

Heavy duty stud-connection mounting

Product parameters

Parameters

Specifications	MSI-300P	MSI-400P	MSI-500P
Continuous output power (Watt)	300	400	500
Output peak power (Watt)	600	800	1000
Input voltage (DC)	12V(11~15V) / 24V(21~30V)
Output voltage (AC)	100~120V / 220~240V
Frequency	50Hz / 60Hz ±3Hz
Output waveform	Modified sine wave
Efficiency	85~90%
Low battery voltage alarm (Volt)	10.5± 0.5V / 21±1V
Low battery voltage shutdown (Volt)	10± 0.5V / 20±1V
Over temperature shutdown	＜65℃
Available protection	Overload protection, input reverse protection, short circuit protection
Cooling mode	By Fan
Replaceable fuse	35A*1	25A*2	30A *2
Accessory	Clamp
Dimension (LWH) mm	16012570	16012570	16012570
Weight (kg)	0.52	0.55	0.65
QTY (pcs)	10	10	10
Carton measurement (mm)	355240450	355240450	355240450
Container 20GP (pcs)	5040	5040	5040
Container 40GP (pcs)	10080	10080	10080
