Specifications | LC-2151 | LC-2152 | LC-2153 | LC-2154 | LC-2155 | LC-2156 | LC-2157 | LC-2158 |
Input voltage | 100~240VAC | 100~240VAC | 100~240VAC | 100~240VAC | 100~240VAC | 100~240VAC | 100~240VAC | 100~240VAC |
Input frequency | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz |
Output voltage | 12V | 12V | 24V | 24V | 24V | 24V | 36V | 36V |
Output current | 10A | 12A | 6A | 7A | 10A | 12A | 5A | 8A |
Battery type (Ah) | 33.3--100 | 40--120 | 20--60 | 23.3--70 | 33.3--100 | 40--120 | 16.7--50 | 30--90 |
Light switching current | 0.2 | 2.4A | 1.2A | 1.4A | 2A | 2.4A | 1A | 1.6A |
Overload protection | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Short circuit protection | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Reverse polarity protection | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
Charging status display | LED | LED | LED | LED | LED | LED | LED | LED |
Case/shell | Metal | Metal | Metal | Metal | Metal | Metal | Metal | Metal |
Dimension(mm) | 208*130*82 | 208*130*82 | 208*130*82 | 208*130*82 | 208*130*82 | 208*130*82 | 208*130*82 | 208*130*82 |
Weight (g) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Certification | CE | CE | CE | CE | CE | CE | CE | CE |
QTY (pcs) | 10 | 10 | 10 | 10 | 10 | 10 | 8 | 8 |
Carton measurement (mm) | 715*300*215 | 715*300*215 | 715*300*215 | 715*300*215 | 715*300*215 | 715*300*215 | 505*320*476 | 505*320*476 |
Container 20GP (pcs) | 3360 | 3360 | 3360 | 3360 | 3360 | 3360 | 2240 | 2240 |
Container 40GP(pcs) | 6720 | 6720 | 6720 | 6720 | 6720 | 6720 | 4480 | 4480 |
