Marxon

Specifications	LC-2290	LC-2291
AC input voltage range	90Vac~264Vac	90~264Vac
AC input voltage rating	100Vac~240Vac	100~240Vac
AC input frequency	50/60Hz	47~63Hz
AC input current	1.2A@120Vac/0.6A@230Vac	1.2A@120Vac
AC input power	78W	140W @120Vac
AC input static state current	0.1A	0.05A
Output voltage range	14-28.8Vdc	14-28.8Vdc
Bulk charge Current rating	2A@24Vdc	3.5A @ 24Vdc
Output power	60W	111W
Bulk charge voltage rating	28.8V	28.8Vdc
Float charge voltage rating	27Vdc	27Vdc
Light switching current	0.5A	0.6A
Efficiency	82%	92%
Over load protection	<3A	<5A
Output start voltage	14V	14V
Short circuit protection	Enable	Enable
Reversed polarity protection	Enable	Enable
Operating temperature	0℃~40℃	0℃~40℃
Storage temperature	-30℃~85℃	-30℃~85℃
Operating relative humidity	8%~90%	8%~90%
Storage relative humidity	5%~95%	5%~95%
Spot test	Burn in 24h at 40℃	Burn in 24 hours at 40℃
Whole test	Burn in 1h at 40℃	Burn in 2 hour at 40℃
Net Weight	450g	500g
Dimension	1587348mm	186mm×73mm×48mm
Enclosure	Plastic case	Metal case
