Marxon

Specification	LC-2659
AC input voltage range	90Vac~264Vac
AC input voltage rating	100Vac~240Vac
AC input frequency	50-60Hz
AC input current	13A
AC input power	1400W
AC input static current	0.2A
Output voltage range	48Vdc
Maximum charging current rating	14A@Input voltage:90-108Vac 19A@48Vdc
output power	1200W
Batch charging voltage rating	58.8V
Rated voltage of float charging	55Vdc
Soft charging current	14V-44V 16A
Bulk1 charging current	44V-56.4V 19A
Bulk2 charging current	56.4V-58.8V 16A
Light switch	2A
Current starting voltage	>14V
Starting current	3A
efficiency	90%
overload protection	<25A
Short circuit protection	YES
Reverse polarity protection	YES
working temperature	-20℃~50℃
Storage temperature	-40℃~85℃
Working relative humidity	5%~90%
Storage relative humidity	5%~95%
Net weight	5Kg
size	326.5194.188mm
Energy standards	D OE
Classification of waterproof materials	Ip67
Withstand voltage (high voltage)	1500Vac ≤10mA (60s)
insulation resistance	>100MΩ @500Vdc
safety standards	FCC
