Specification	LC-5624
Input Property
DC input voltage rating	12V DC
DC input voltage range	11 to 16V DC
Low battery alarm	11V±0.2V DC
No load current draw	<0.6A @13.2VDC
High battery voltage shutdown	16.5V±0.2V DC
Fuse (internal)	25A×1(MAX)
Input reverse protection	Yes
Output Property
Output voltage range	220V AC (RMS)
Output frequency	50Hz
Output wave form	Pure Sine Wave
Max output power	150W
Overload protection power	180W~225W
Leakage protection current	<3.5mA
insulation resistance	>1MΩ
Withstand Voltage (Hi-Pot)	1500Vac 10mA (60 Sec.)
General Characteristics
Efficiency(except power loss on the wire)	>85%
Short circuit protection	YES
Over load protection	YES
Over temperature shutdown	>85℃±10℃
Operating temperature range	-20-50℃
Storage temperature range	-40-85℃
Operating relative humidity	10%-90%
Storage relative humidity	5%-95%
Mechanical Characteristics
Dimension	165mm116.8mm47.5mm
Net weight	0.73kg
Outlet	THB 10PIN Wire harness plug
Outlet	National standard 5-hole socket
Output line length	700mm
Input interface	THB 4PIN Wire harness plug
