Marxon

Technical Specification	MKS-HW10K-XLV3P	MKS-HW12K-XLV3P	MKS-HW15K-XLV3P
RATED OUTPUT POWER	10000W	12000W	15000W
PVINPUT(DC)
Nominal DC Voltage/Maximum DC Voltage	720 VDC /1000 VDC	720 VDC / 1000 VDC	720 VDC / 1000 VDC
Start-up Voltage/Initial Feeding Voltage	320VDC /350 VDC
MPP Voltage Range	350 -950VDC	350 -950VDC	350 -950VDC
Number of MPP Trackers/Maximum Input Current	2 / A: 27 A， B: 27A	2 / A: 27 A， B: 27A	2 / A: 27 A， B: 27A
Number of Strings Per MPP Tracker	A: 2. B: 2	A: 2. B: 2	A: 2. B: 2
GRID-TIE OPERATION
GRID OUTPUT(AC)
GRID OUTPUT (AC)
Nominal Output Voltage	230 VACIP-N) / 400 VAC (P-P)
Output Voltage Range	184 -265 VAC perphase
Nominal Output Current	14 .5 A perphase	17 .4 A perphase	21 .7 A perphase
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage /Auto Restart Voltage	120 -140 VAC /180 VAC
Ac ceptable Input Voltage Range	170 -290 VAC perphase
Maximum AC Input Current	40A	40A	40A
PV INPUT(DC)
Maximum DC Power	14500W	16000W	22500W
Maximum DC Voltage	1000VDC	1000VDC	1000VDC
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	230 VAC (PN) /400 VAC IP-P)
Output Waveform	Puresine wave
Efficiency (DC to AC)	91%	91%	91%
HYBRID OPERATION
PVINPUT (DC)
Maximum DC Voltage	14500W	16000W	22500W
Start-up Voltage / Initial Feeding Voltage	320 VDC /350 VDC
GRID OUTPUT(AC)
Nominal Output Voltage	230 VAC (P -N) / 400 VAC IP P)
Output Voltage Range	184 - 265 VAC per phase
Nominal Output Current	14 .5 A perphase	17.4 A perphase	21.7 A perphase
AC INPUT
AC Startup Voltage /Auto Restart Voltage	120 - 140 VAC / 180 VAC
Acceptable Input Voltage Range	170 - 290 VAC perphase
Maximum AC Input Current	40 A	40 A	40 A
BATTERY MODE OUTPUT(AC)
Nominal Output Voltage	230 VAC IPN) / 400 VAC (P-P)
Efficiency (DC to AC)	91%	91%	91%
BATTERY & CHARGER
Battery Voltage Range	40 ~62 VDC	40 ~62 VDC	40-62 VDC
Maximum Charging Current	200 A	250 A	300 A
GENERAL
PHYSICAL
Dimension, D x W x H (m m)	255 X 660 X 750
Net Weight (kgs)	70	70	70
INTERFACE
Communication Port	RS-232，RS485, USB, CAN and WiFi
Intelligent Slot	Optional for SNMP and Modb us cards
