G3600

Power Station 3072Wh

This product is an energy storage power supply with a built-in 51.2V 60Ah LiFePO4 battery, integrated inverter power supply, multiple USB interfaces, and DC12V power output functions. It has an AC output of 120V/220V/230V 50/60Hz and a total output power of 3600W. This product supports solar charging, mains AC charging, UPS function, and multifunctional LCD display. It is an ideal energy storage power supply product.

The product adopts LCD display, and the battery status is displayed simultaneously on your phone.

Product features

Features

Core Specifications

• Built-in 51.2V 60Ah LiFePO4 battery with integrated inverter power supply.

Output Options

• Multiple USB interfaces, DC12V power output, and AC output (120V/220V/230V 50/60Hz) with total power of 3600W.

Charging & Features

• Supports solar charging, mains AC charging, UPS function, and multifunctional LCD display.

Display & Monitoring

• LCD display shows status, which is simultaneously visible on your phone via remote monitoring.

Product parameters

Parameters

Projects	G3600	G3600	Remark
Rated input voltage	51.2VDC	51.2VDC
Output voltage range	120V AC (RMS)	230V AC (RMS)	±10%
Output voltage frequency	50/ 60Hz power grid adaptive	50/ 60Hz power grid adaptive	±3Hz
Output voltage waveform	Pure sine wave	Pure sine wave
Continuous output power	3600W	3600W
The peak output	7200W	7200W
The cooling way	Fan	Fan	Temperature-controlled opening
Ac output interface	EP34PCS&TT-30 1PC	Euro / UK socket *4PCS	Customizable
Serial parallel interface	5+8-50A connectors	5+8-50A connectors
UPS switching time	≤10ms	≤10ms
Regular USB(black)*2PCS	No load/ load voltage: 5V	No load / load voltage: 5V	±0 3V
Regular USB(black)*2PCS	Load current: 2.4A	Load current: 2.4A	±0 .3A
Fast charge USB(blue)*2PCS	20V 3A 60W	20V 3A 60W	When the fast charge and the C port are both working, the default 5V output
Type-C PD*2PCS	20 V5A 100W	20V 5A 100W
DC output	12V 10A 120W	12V 10A 120W
AC input voltage	100VAC~ 135VAC	180VAC~264VAC	±5VAC
AC Charging power slow charge/fast charge	600W/1800W	1800W	Max
Input voltage	12-60V	12-60V	12-60V
Solar input power	≤1500W	≤1500W	≤1500W
Solar controller input current	25A	25A	Max
Products dimension	46 9356446mm	469356446mm
Battery specification	51.2V 60AH(3072Wh) L1FeP04 Battery	51.2V60AH (3072Wh) L1FeP04 Battery
